Little Firefighter VAGV-100 Seismic Gas Shut-Off Valve – 1" Vertical
Little Firefighter VAGV-100 Seismic Gas Shut-Off Valve – 1" Vertical
Couldn't load pickup availability
Product Description:
The VAGV-100 is a vertical-style 1" seismic gas shut-off valve designed by Little Firefighter to automatically close the gas line during seismic activity of ~5.4 magnitude or higher. Ideal for residential and light commercial gas systems, it ensures compliance with California earthquake safety codes and provides crucial protection from gas leaks or fire hazards after a quake.
Made from a rugged aluminum body with brass and stainless steel internals, the VAGV-100 is UL/CSA listed and Los Angeles RR# 5349 approved. It installs in a vertical top-inlet orientation and features a dual manual reset system after activation.
Key Features:
-
1" FNPT vertical (top-inlet) configuration
-
Automatically shuts off gas at ~5.4 magnitude ground motion
-
Aluminum body with brass/stainless steel components
-
Rated for gas pressures up to 10 psi
-
Manual reset required on both inlet and outlet sides
-
Certified to ASCE 25-97, ANSI Z21.70
-
UL/CSA listed and LA City approved
Why Choose the VAGV-100:
-
Designed for vertical installations with 1" gas lines
-
Complies with seismic shut-off requirements across California
-
Reliable, corrosion-resistant build for long-term use
-
Installs quickly and performs passively until triggered
Applications:
-
Upstream of Navien water heaters, boilers, or other gas appliances
-
Vertical gas risers at residential or light commercial buildings
-
Retrofit safety upgrades and code-compliant new construction
